Veria Control T45 is a programmable thermostat with a timer that will allow you to regulate the temperature of your underfloor heating in accordance with the temperature of the floor, the air temperature in the room or a combination of these temperatures. The 5+2 day mode allows you to program the thermostat to match Your needs. Each day is divided into 4 individual time zones, each of which allows you to have the right temperature at the right time. The use of timer programming will save you money as the system operates at a certain time of day.
Top-notch user-friendliness: The Veria Control T45 is an advanced, but easy-to-use, digital timer-controlled thermostat with a large LCD digital that can be used to control your floor heating via a floor sensor, room sensor, or a combination of the two.
Save energy: The Veria Control T45 is equipped with a weekday and weekend programme, both of which can be used to divide a given day into four time zones. This means you can opt to only heat your floor/room during the necessary periods in order to save both energy and money.
Modern design: With its elegant and discreet design, and with a thickness of only 14 mm on the wall, the Veria Control T45 fits nicely in any room and in any home.
Installation and connection:
Before installing the thermostat on the wall in the mounting box, open the front panel of the thermostat by gently pressing the latches located at the bottom of the thermostat.
Connect the wires according to the diagram (see below) and fix the thermostat in the socket with screws. Check that all connections are correct and reinstall the front.
Main functions:
SET LIMIT MAX. FLOOR TEMPERATURES
This function is mainly used for wooden floors and is only available in combined modes using a floor and room temperature sensor (modes 3 and 5).
In this case, the limitation should not exceed 35°C. This value is set on the thermostat by default.
If you select only floor temperature control mode with floor sensor (mode 2), the maximum floor temperature limit is set to 35°C and cannot be changed.
Changing the maximum temperature limit floor (mode 3 and 5)
The thermostat must be turned off.
Press and hold for 10 seconds. button "M" until "Up" appears on the display.
After that, release the "M" button and the display "SET" will appear.
Now you can install using the buttons "Up" and "Down" limiting the maximum floor temperature (range from 20°C to 45°C).
FLOOR TEMPERATURE DISPLAY (only for 3 and 5)
The thermostat must be turned on.
Press the "M" button once, and the symbol will appear on the display "FT" and the displayed temperature will be the current floor temperature.
In mode 2 (floor sensor), the display always shows the current floor temperature.
In modes 1 and 4 (air temperature sensor) the display always shows the current room temperature is displayed.
FROST PROTECTION MODE
To enable this mode, the thermostat must be turned off.
Press and hold for 3 sec. the "M" button. Set using the “Up” and “Down ” buttons 01. (00 = disable mode)
When this mode is set and the thermostat is turned off, heating will be switched on if the floor/air temperature is below 5°C; heating will be turned off if the air temperature will be above 7°C.
The display will show the “Frost protection mode” Symbol
Important Note: The thermostat must be installed by a qualified electrician.
Box Contains: 1x Veria control T45 digital thermostat
